AT Clutch (Low-3rd) for 2012 Acura TSX

Diagram 1 1. GUIDE, CLUTCH (1-3) Diagram 2 2. GUIDE, CLUTCH (1-3)
AT Clutch (Low-3rd) for 2012 Acura TSX #0
1
1
2
2
3
3
4
4
5
5
6
6
7
7
7
7
8
8
8
8
8
8
8
8
8
8
9
9
9
9
10
10
10
10
10
10
10
10
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
12
12
13
13
14
14
15
15
15
15
16
16
16
16
17
17
17
17
18
18
19
19
No.
Part # / Description / Price
Price
1
22510RCLA02 - Transmission - Automatic: GUIDE, CLUTCH (1-3) for Acura Image
Guide, Clutch (1-3)
22510-RCL-A02
Acura Acura
MSRP $178.72
$123.31
MSRP $178.72
$123.31
2
22521RCLA01 - Transmission - Automatic: PISTON, CLUTCH for Acura Image
Piston, Clutch
22521-RCL-A01
Acura Acura
MSRP $103.14
$73.02
MSRP $103.14
$73.02
3
22533RCLA01 - Transmission - Automatic: RETAINER, RETURN SPRING for Acura Image
Retainer, Return Spring
22533-RCL-A01
Acura Acura
MSRP $69.62
$50.12
MSRP $69.62
$50.12
4
22534R90003 - Transmission - Automatic: RETAINER, RETURN SPRING for Acura Image
Retainer, Return Spring
22534-R90-003
Acura Acura
MSRP $44.88
$33.66
MSRP $44.88
$33.66
5
22536RCLA01 - Transmission - Automatic: SPRING, CLUTCH WAVE for Acura Image
Spring, Clutch Wave
22536-RCL-A01
Acura Acura
MSRP $21.74
$16.31
MSRP $21.74
$16.31
6
22537RCLA01 - Transmission - Automatic: SPRING, CLUTCH WAVE for Acura Image
Spring, Clutch Wave
22537-RCL-A01
Acura Acura
MSRP $21.74
$16.31
MSRP $21.74
$16.31
7
22541RCLA01 - Transmission - Automatic: SPRING, CLUTCH RETURN (F.C.C.) for Acura Image
Spring, Clutch Return (F.C.C.)
22541-RCL-A01
Acura Acura
MSRP $32.95
$24.71
MSRP $32.95
$24.71
8
22543RCLA01 - Transmission - Automatic: PLATE, CLUTCH WAVE (1.6MM) for Acura Image
Plate, Clutch Wave (1.6MM)
22543-RCL-A01
Acura Acura
MSRP $21.66
$16.24
MSRP $21.66
$16.24
9
22543RCLA11 - Transmission - Automatic: PLATE, CLUTCH (1.6MM) for Acura Image
Plate, Clutch (1.6MM)
22543-RCL-A11
Acura Acura
MSRP $21.10
$15.83
MSRP $21.10
$15.83
10
22543RCLJ01 - Transmission - Automatic: PLATE, CLUTCH WAVE (1.6MM) for Acura Image
Plate, Clutch Wave (1.6MM)
22543-RCL-J01
Acura Acura
MSRP $21.66
$16.24
MSRP $21.66
$16.24
11
22544R91003 - Transmission - Automatic: DISK, CLUTCH for Acura Image
Disk, Clutch
22544-R91-003
Acura Acura
MSRP $44.03
$33.03
MSRP $44.03
$33.03
12
22552RCLA01 - Transmission - Automatic: PLATE, CLUTCH END (2) (2.2MM) for Acura Image
Plate, Clutch End (2) (2.2MM)
22552-RCL-A01
Acura Acura
MSRP $42.50
$31.88
MSRP $42.50
$31.88
12
22558RCLA01 - Transmission - Automatic: PLATE, CLUTCH END (8) (2.8MM) for Acura Image
Plate, Clutch End (8) (2.8MM)
22558-RCL-A01
Acura Acura
MSRP $42.50
$31.88
MSRP $42.50
$31.88
12
22553RCLA01 - Transmission - Automatic: PLATE, CLUTCH END (3) (2.3MM) for Acura Image
Plate, Clutch End (3) (2.3MM)
22553-RCL-A01
Acura Acura
MSRP $42.50
$31.88
MSRP $42.50
$31.88
12
22557RCLA01 - Transmission - Automatic: PLATE, CLUTCH END (7) (2.7MM) for Acura Image
Plate, Clutch End (7) (2.7MM)
22557-RCL-A01
Acura Acura
MSRP $42.50
$31.88
MSRP $42.50
$31.88
12
22556RCLA01 - Transmission - Automatic: PLATE, CLUTCH END (6) (2.6MM) for Acura Image
Plate, Clutch End (6) (2.6MM)
22556-RCL-A01
Acura Acura
MSRP $42.50
$31.88
MSRP $42.50
$31.88
12
22559RCLA01 - Transmission - Automatic: PLATE, CLUTCH END (9) (2.9MM) for Acura Image
Plate, Clutch End (9) (2.9MM)
22559-RCL-A01
Acura Acura
MSRP $42.50
$31.88
MSRP $42.50
$31.88
12
22555RCLA01 - Transmission - Automatic: PLATE, CLUTCH END (5) (2.5MM) for Acura Image
Plate, Clutch End (5) (2.5MM)
22555-RCL-A01
Acura Acura
MSRP $42.50
$31.88
MSRP $42.50
$31.88
12
22554RCLA01 - Transmission - Automatic: PLATE, CLUTCH END (4) (2.4MM) for Acura Image
Plate, Clutch End (4) (2.4MM)
22554-RCL-A01
Acura Acura
MSRP $42.50
$31.88
MSRP $42.50
$31.88
12
22551RCLA01 - Transmission - Automatic: PLATE, CLUTCH END (1) (2.1MM) for Acura Image
Plate, Clutch End (1) (2.1MM)
22551-RCL-A01
Acura Acura
MSRP $42.50
$31.88
MSRP $42.50
$31.88
13
22576R91003 - Transmission - Automatic: PLATE, CLUTCH END (6) (3.1MM) for Acura Image
Plate, Clutch End (6) (3.1MM)
22576-R91-003
Acura Acura
MSRP $32.50
$24.38
MSRP $32.50
$24.38
13
22577R91003 - Transmission - Automatic: PLATE, CLUTCH END (7) (3.2MM) for Acura Image
Plate, Clutch End (7) (3.2MM)
22577-R91-003
Acura Acura
MSRP $32.50
$24.38
MSRP $32.50
$24.38
13
22579R91003 - Transmission - Automatic: PLATE, CLUTCH END (9) (3.4MM) for Acura Image
Plate, Clutch End (9) (3.4MM)
22579-R91-003
Acura Acura
MSRP $32.50
$24.38
MSRP $32.50
$24.38
13
22578R91003 - Transmission - Automatic: PLATE, CLUTCH END (8) (3.3MM) for Acura Image
Plate, Clutch End (8) (3.3MM)
22578-R91-003
Acura Acura
MSRP $32.50
$24.38
MSRP $32.50
$24.38
13
22575R91003 - Transmission - Automatic: PLATE, CLUTCH END (5) (3.0MM) for Acura Image
Plate, Clutch End (5) (3.0MM)
22575-R91-003
Acura Acura
MSRP $32.50
$24.38
MSRP $32.50
$24.38
13
22572R91003 - Transmission - Automatic: PLATE, CLUTCH END (2) (2.7MM) for Acura Image
Plate, Clutch End (2) (2.7MM)
22572-R91-003
Acura Acura
MSRP $32.50
$24.38
MSRP $32.50
$24.38
13
22574R91003 - Transmission - Automatic: PLATE, CLUTCH END (4) (2.9MM) for Acura Image
Plate, Clutch End (4) (2.9MM)
22574-R91-003
Acura Acura
MSRP $32.50
$24.38
MSRP $32.50
$24.38
13
22573R91003 - Transmission - Automatic: PLATE, CLUTCH END (3) (2.8MM) for Acura Image
Plate, Clutch End (3) (2.8MM)
22573-R91-003
Acura Acura
MSRP $32.50
$24.38
MSRP $32.50
$24.38
13
22571R91003 - Transmission - Automatic: PLATE, CLUTCH END (1) (2.6MM) for Acura Image
Plate, Clutch End (1) (2.6MM)
22571-R91-003
Acura Acura
MSRP $32.50
$24.38
MSRP $32.50
$24.38
14
22671RCLA01 - Transmission - Automatic: PISTON, THIRD CLUTCH for Acura Image
Piston, Third Clutch
22671-RCL-A01
Acura Acura
MSRP $123.76
$87.63
MSRP $123.76
$87.63
15
90603P6H003 - Transmission - Automatic: CIRCLIP (OUTER) (43MM) for Acura Image
Circlip (Outer) (43MM)
90603-P6H-003
Acura Acura
MSRP $9.50
$7.13
MSRP $9.50
$7.13
16
90605RCLA01 - Transmission - Automatic: RING, SNAP (131.2MM) for Acura Image
Ring, Snap (131.2MM)
90605-RCL-A01
Acura Acura
MSRP $12.09
$9.06
MSRP $12.09
$9.06
17
91302K0G911 - Transmission - Automatic: O-RING (39.8X2.2) (ARAI) for Acura Image
O Ring (39.8X2.2)
91302-K0G-911
Acura Acura
MSRP $5.28
$3.96
MSRP $5.28
$3.96
18
91303PX4004 - Transmission - Automatic: O-RING (114X2.2) (NOK) for Acura Image
O-Ring (114X2.2) (Nok)
91303-PX4-004
Acura Acura
MSRP $13.75
$10.31
MSRP $13.75
$10.31
19
91304RCLA01 - Transmission - Automatic: O-RING (116.1X2.2) (F.C.C.) for Acura Image
O-Ring (116.1X2.2) (F.C.C.)
91304-RCL-A01
Acura Acura
MSRP $11.65
$8.74
MSRP $11.65
$8.74
